Siemens simatic et200sp User Manual

Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
92 Manual, 12/2015, A5E36061895-AA
Technical specifications
14
14.1
Technical specifications
Technical specifications of the AI Energy Meter 480VAC ST 6ES7134-6PA20-0BD0
6ES7134-6PA20-0BD0
General information
Product type designation
AI Energy Meter 480VAC ST
Usable BaseUnits
BU type D0, BU20-P12+A0+0B
Color code for module
-specific color identification
label
CC00
Product function
Voltage measurement
Yes
Voltage measurement with voltage transformer
Yes
Current measurement
Yes
Phase current measurement without current tran
s-
former
No
Phase current measurement with current tran
s-
former
Yes
Energy measurement
Yes
Frequency measurement
Yes
Power measurement
Yes
Active power measurement
Yes
Reactive power measurement
Yes
I&M data
Yes
Isochronous mode
No
Operating mode
Cyclic measurement
Yes
Acyclic measurement
Yes
Configuration control
Via user data
Yes
Via data record
Yes
Installation type / mounting
Installation position
Any
Supply voltage
Description
Supply via voltage measurement channel L1
Type of supply voltage
100 - 277 V AC
Permissible range, low limit (AC)
90 V
Permissible range, high limit (AC)
293 V

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
