Measured value data records
E.4 Measured value data record for maximum values (DS 144)
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
164 Manual, 12/2015, A5E36061895-AA
E.4
Measured value data record for maximum values (DS 144)
Measured variables of the module
The largest values ever measured or calculated from the time AI Energy Meter 480VAC ST
was started are stored in this data record.
Byte
Measured variable
Format
Unit
Default
Measured
value ID
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
0
Version
BYTE
-
0
-
✓
✓
✓
✓
✓
1
Reserved
BYTE
-
0
-
✓
✓
✓
✓
✓
2...5 Max. voltage UL1-N REAL V 0 40 ✓ ✓ ✓ ✓ ✓
6...9
Max. voltage UL2-N
REAL
V
0
41
✓
✓
✓
✓
10...13 Max. voltage UL3-N REAL V 0 42 ✓ ✓ ✓
14...17
Max. voltage UL1-L2
REAL
V
0
43
✓
✓
18...21
Max. voltage UL2-L3
REAL
V
0
44
✓
✓
22...25
Max. voltage UL3-L1
REAL
V
0
45
✓
✓
26...29
Max. current L1
1
REAL
A
0
46
✓
✓
✓
✓
✓
30...33
Max. current L2
1
REAL
A
0.
47
✓
✓
✓
✓
34...37
Max. current L3
1
REAL
A
0
48
✓
✓
✓
38...41 Max. apparent pow-
er L1
REAL VA 0 49 ✓ ✓ ✓ ✓ ✓
42...45 Max. apparent pow-
er L2
REAL VA 0 50 ✓ ✓ ✓ ✓
46...49 Max. apparent pow-
er L3
REAL VA 0 51 ✓ ✓ ✓
50...53 Max. active
power L1
REAL W -3.0 x 10
9
52 ✓ ✓ ✓ ✓ ✓
54...57 Max. active
power L2
REAL W -3.0 x 10
9
53 ✓ ✓ ✓ ✓
58...61 Max. active
power L3
REAL W -3.0 x 10
9
54 ✓ ✓ ✓
62...65 Max. reactive
power L1
REAL var -3.0 x 10
9
55 ✓ ✓ ✓ ✓ ✓
66...69 Max. reactive
power L2
REAL var -3.0 x 10
9
56 ✓ ✓ ✓ ✓
70...73 Max. reactive
power L3
REAL var -3.0 x 10
9
57 ✓ ✓ ✓
74...77 Max. power
factor L1
REAL - 0 58 ✓ ✓ ✓ ✓ ✓
78...81 Max. power
factor L2
REAL - 0 59 ✓ ✓ ✓ ✓
82...85 Max. power
factor L3
REAL - 0 60 ✓ ✓ ✓
86...89
Max. frequency
REAL
Hz
45
61
✓
✓
✓
✓
✓
