Measured value data records
E.3 Structure for energy counters (DS 143)
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
163
Error while transferring the data record
The module always checks all the values of the transferred data record. Only if all the values
were transferred without errors does the module apply the values from the data record.
The WRREC instruction for writing data records returns corresponding error codes when
errors occur in the STATUS parameter.
The following table shows the module-specific error codes and their meaning for the
measured value data record 143:
Error code in STATUS parameter
(hexadecimal)
DF 80 B0 00 Number of the data record unknown Enter a valid number for the data
record.
DF 80 B1 00 Length of the data record incorrect
Enter a valid value for the data record
length.
DF 80 B2 00 Slot invalid or cannot be accessed. Check the station whether the mod-
ule is plugged or drawn.
Check the assigned values for the
parameters of the WRREC instruction
DF 80 E1 01 Reserved bits are not 0.
Check Byte 2...7 and set the reserved
bits back to 0.
Incorrect version entered.
Check Byte 0. Enter a valid version.
DF 80 E1 3A Incorrect data record length entered. Check the parameters of the WRREC
instruction. Enter a valid length.
DF 80 E1 3C At least one start value is invalid. Check Bytes 8...103 and Bytes
158...169. The start values may not
DF 80 E1 3D At least one start value is too large Check Bytes 8...103 and Bytes
158...169. Observe the ranges of
