Product overview
2.2 Properties of the AI Energy Meter 480VAC ST
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
14 Manual, 12/2015, A5E36061895-AA
Properties
The module has the following technical properties:
● Measurement of electrical variables from single-phase, two-phase and three-phase
supply networks
● Max. nominal voltage between two outer conductors 480 VAC
● Retentive storage of the counter values
● Recording of:
– Voltages
– Currents
– Phase angles
– Power
– Energy / electrical work
– Frequencies
– Minimum and maximum values
– Power factors
– Operating hours
– Limits
The module supports the following functions:
● Firmware update
● Calibration in runtime
● I&M identification data
● Reconfiguration in RUN
● Diagnostics and hardware interrupts
Accessories
The following accessories must be ordered separately:
● BaseUnit Type D0
● Labeling strips
● Reference identification label
You can find additional information on the accessories in the ET 200SP distributed I/O
system (http://support.automation.siemens.com/WW/view/es/58649293) system manual.

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
