Siemens simatic et200sp User Manual

User data variants
D.1 User data variants with 32 bytes input data / 12 bytes output data
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
151
Basic variables phase-specific measurement (ID 157 or 9D
H
)
Table D- 20 Basic variables phase-specific measurement L2
Byte
Allocation
Data type
Unit
Value range
Measured
value ID
0
User data variant
BYTE
-
157 (9D
H
)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit string qq xx xx xx -
2 ... 3
Current L2
UINT
1 mA
0 … 65535
66008
4 ... 5
Voltage UL2-N
UINT
0.01 V
0 … 65535
66002
6 ... 7
Active power L2
INT
1 W
-27648 … 27648
66014
8 ... 9
Reactive power L2
INT
1 var
-27648 … 27648
66017
10 ... 11
Apparent power L2
INT
1 VA
-27648 … 27648
66011
12 ... 15
Active energy L2 total (inflow - outflow)
UDINT
1 Wh
0 … 4294967295
62215
16 ... 19
Reactive energy L2 total (inflow - outflow)
UDINT
1 varh
0 … 4294967295
62216
20 ... 23
Apparent energy L2
UDINT
1 VAh
0 … 4294967295
62214
24
Scaling current L2
USINT
-
0 ... 255
-
25
Scaling active power L2
USINT
-
0 ... 255
-
26
Scaling reactive power L2
USINT
-
0 ... 255
-
27
Scaling apparent power L2
USINT
-
0 ... 255
-
28
Scaling active energy L2 total (inflow - outflow)
USINT
-
0 ... 255
-
29
Scaling reactive energy L2 total (inflow - outflow)
USINT
-
0 ... 255
-
30
Scaling apparent energy L2
USINT
-
0 ... 255
-
31
Power factor L2
USINT
0.01
0 … 100
66020
