Measured value data records
E.7 Measured value data record for phase-based measured values L2 (DS 148)
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
168 Manual, 12/2015, A5E36061895-AA
Byte
Measured varia-
ble
Format
Unit
Value range
Meas-
ured
value
ID
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
2...3 Qualifier L2 WORD Bit
field
0b 00 00 00 00
0b qq 00 00 xx
65501 ✓ ✓ ✓ ✓
4...7
Voltage UL1-N
REAL
V
0.0 ... 1000000.0
2
✓
✓
✓
✓
8...11
Current L2
REAL
A
0.0 … 100000.0
8
✓
✓
✓
✓
12...15 Apparent power
L2
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
11 ✓ ✓ ✓ ✓
16...19 Active power L2 REAL W -3.0 x 10
9
…
+3.0 x 10
9
14 ✓ ✓ ✓ ✓
20...23 Reactive power
L2
REAL var -3.0 x 10
9
…
+3.0 x 10
9
17 ✓ ✓ ✓ ✓
24...27
Power factor L2
REAL
-
0.0 ... 1.0
20
✓
✓
✓
✓
28...31
Phase angle L2
REAL
°
0.0 ... 360.0
61198
✓
✓
✓
✓
32...39 Apparent energy
L2
LREAL VAh 0.0 ... 1.8 x 10
308
61204 ✓ ✓ ✓ ✓
40...47 Active energy
(total) L2
LREAL Wh 0.0 ... 1.8 x 10
308
61205 ✓ ✓ ✓ ✓
48...55 Reactive energy
(total) L2
LREAL varh 0.0 ... 1.8 x 10
308
61206 ✓ ✓ ✓ ✓
56...59 Max. voltage
UL1-N
REAL V 0.0 ... 1000000.0 41 ✓ ✓ ✓ ✓
60...63
Max. current L2
REAL
A
0.0 ... 100000.0
47
✓
✓
✓
✓
64...67 Max. apparent
power L2
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
50 ✓ ✓ ✓ ✓
68...71 Max. active pow-
er L2
REAL W -3.0 x 10
9
…
+3.0 x 10
9
53 ✓ ✓ ✓ ✓
72...75 Max. reactive
power L2
REAL var -3.0 x 10
9
…
+3.0 x 10
9
56 ✓ ✓ ✓ ✓
76...79 Max. power factor
L2
REAL - 0.0 ... 1.0 59 ✓ ✓ ✓ ✓
80...83 Min. voltage UL1-
N
REAL V 0.0 ... 1000000.0 71 ✓ ✓ ✓ ✓
84...87
Min. current L2
REAL
A
0.0 ... 100000.0
77
88...91 Min. apparent
power L2
REAL VA -3.0 x 10
9
…
+3.0 x 10
9
80 ✓ ✓ ✓ ✓
92...95 Min. active power
L2
REAL W -3.0 x 10
9
…
+3.0 x 10
9
84 ✓ ✓ ✓ ✓
96...99 Min. reactive
power L2
REAL var -3.0 x 10
9
…
+3.0 x 10
9
86 ✓ ✓ ✓ ✓
100...103 Min. power factor
L2
REAL - 0.0 ... 1.0 89 ✓ ✓ ✓ ✓
