Measured value data records
E.9 Measured value data record for advanced measurement and status values (DS 150)
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
171
Byte
Measured variable
Format
Unit
Value range
Measured
value ID
62...65
Counter limit violation GW 11
UDINT
-
0 ... 4294967296
65520
66...69 Counter limit violation GW 12 UDINT - 0 ... 4294967296 65521
70...73
Counter limit violation GW 13
UDINT
-
0 ... 4294967296
65522
74...77
Counter limit violation GW 14
UDINT
-
0 ... 4294967296
65523
78...81
Counter limit violation GW 15
UDINT
-
0 ... 4294967296
65524
82..85
Counter limit violation GW 16
UDINT
-
0 ... 4294967296
65525
86..87
Qualifier L1L2L3
WORD
Bit string
xxxx xxxx xxxx xxxx
65503
1
Energy counters count periodically - counter overflow at:
Bit 0 = 1: Active energy inflow L1
Bit 1 = 1: Active energy outflow L1
Bit 2 = 1: Reactive energy inflow L1
Bit 3 = 1: Reactive energy outflow L1
Bit 4 = 1: Apparent energy L1
Bit 5 = 1: Active energy inflow L2
Bit 6 = 1: Active energy outflow L2
Bit 7 = 1: Reactive energy inflow L2
Bit 8 = 1: Reactive energy outflow L2
Bit 9 = 1: Apparent energy L2
Bit 10 = 1: Active energy inflow L3
Bit 11 = 1: Active energy outflow L3
Bit 12 = 1: Reactive energy inflow L3
Bit 13 = 1: Reactive energy outflow L3
Bit 14 = 1: Apparent energy L3
Bit 15: Reserved
