Energy counters
7.5 Data record for energy counter (DS 143)
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
56 Manual, 12/2015, A5E36061895-AA
Byte
Measured variable
Data type
Unit
Value range
Measured
value ID
128...129
Overflow counter active energy inflow L1
UINT
-
During reading:
0...65535
During writing for contin-
uous counting:
0
During writing for periodic
counting:
0...65500
61190
130..131 Overflow counter active energy outflow L1 UINT - 61191
132...133
Overflow counter reactive energy inflow L1
UINT
-
61192
134...135
Overflow counter reactive energy outflow L1
UINT
-
61193
136...137
Overflow counter apparent energy L1
UINT
-
61194
138...139
Overflow counter active energy inflow L2
UINT
-
61210
140...141
Overflow counter active energy outflow L2
UINT
-
61211
142...143
Overflow counter reactive energy inflow L2
UINT
-
61212
144...145
Overflow counter reactive energy outflow L2
UINT
-
61213
146...147
Overflow counter apparent energy L2
UINT
-
61214
148...149
Overflow counter active energy inflow L3
UINT
-
61230
150...151
Overflow counter active energy outflow L3
UINT
-
61231
152...153
Overflow counter reactive energy inflow L3
UINT
-
61232
154...155
Overflow counter reactive energy outflow L3
UINT
-
61233
156...157
Overflow counter apparent energy L3
UINT
-
61234
158...161
Operating hours counter L1 (initial value)
REAL
h
During reading:
0...3.4x10
38
During writing:
0...10
9
65505
162...165
Operating hours counter L2 (initial value)
REAL
h
65506
166...169 Operating hours counter L3 (initial value) REAL h 65507
