Interrupts/diagnostic alarms
13.3 Diagnostic alarms
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
89
Table 13- 6 Error types
1
Line voltage (measuring range) is moni-
tored for tolerance. Violation leads to volt-
Observe the line voltage range
Overvoltage 3
H
Overload 4
H
The measured current is monitored after
expiration of the "Tolerance time" for "Tol-
erance factor × Measured current". Ex-
ceeding this results in overflow current.
The maximum value of the secondary
current (12 A) has been exceeded.
Observe the current range
High limit 7
H
Cumulative overflow in the calculated val-
-
Low limit
1
8
H
Violation of the low limit for voltage meas-
urement. The message occurs when the
configured minimum current or voltage is
Observe the voltage range
Error 9
H
Internal module error (diagnostic alarm on
channel 0 applies to the entire module).
Replace the module
Parameter assignment
error
10
H
• The module cannot evaluate parame-
ters for the channel.
• Incorrect parameter assignment.
Correct the parameter assignment
Load voltage missing 11
H
Missing or insufficient line voltage on
Check supply
Channel is temporarily
unavailable
1F
H
Firmware upgrade is being performed.
Channel 0 applies to the entire module.
The module is currently not performing any
--
A user calibration is being executed at the
channel.
Complete the user calibration
If the "Undervoltage" and "Low limit" diagnostics are active at the same time, the "Low limit" diagnostics has higher
priority and deletes the "Undervoltage" diagnostics.
