Commissioning the device
4.3 Parameterizing the Comfort Panel
Comfort Panels
134 Operating Instructions, 08/2018, A5E36770603-AC
12. Save the settings using "Apply" and close the dialog box with "OK".
13. Press the "Start Web-Server" button to start the Web Server on the HMI device.
Use the "Close Web-Server" button to close Web Server.
14. Close the dialog with "OK".
When the Web Server is started, you can use a Web browser to access the service pages
available on the HMI device by default, additional pages you have configured yourself or
other Internet pages. You can access the tags of the server HMI device with a client via a
configured HTTP connection.
Additional information on configuration, types of access and certificates is available in the
TIA information system under:
"Visualize processes > Options > WinCC Sm@rtServer".
4.3.11 Functions for service and commissioning
4.3.11.1 Saving to external storage medium – backup
You can use this function to back up the operating system, applications and data from the
flash memory of the HMI device to an external storage medium.
Use a SIMATIC HMI Memory card or an industry-compatible USB stick as the storage
medium.
Requirement
● The Control Panel is open.
● There is a storage medium with sufficient free capacity in the HMI device.
● Data that must not be overwritten has been saved.
Procedure
1. Open the "Service & Commissioning" dialog using the "Service & Commissioning" icon.
Data that can be backed up
