8.12 Scope of functions with WinCC
Comfort Panels
226 Operating Instructions, 08/2018, A5E36770603-AC
Tags, values and lists
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Tags Quantity 1024 2048 4096
Limit value monitoring
Input/output
Yes
Linear scaling Input/output Yes
Text lists
Quantity
300
500
1
Graphics lists
Quantity
100
500
1
1
The maximum total of text and graphics lists is 500.
Screens
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Screens
Quantity
500
750
Objects per screen
50
400
600
Tags per screen
50
400
600
Complex objects per
screen (for example, bars)
5 20 40
Template
Yes
Recipes
Object
Specification
HMI devices
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort,
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Recipes
Quantity
100
300
500
Data records per recipe
200
500
1000
Entries per data record
200
1000
2000
Recipe memory
512 KB
2 MB
4 MB
Storage location
1
• Memory card (MMC/SD)
• USB storage medium
• Network drive
1
The number of recipe data records may be restricted by the capacity of the storage medium.
