Siemens SIMATIC HMI - Electromagnetic Compatibility

Technical information
8.3 Electromagnetic compatibility
Comfort Panels
188 Operating Instructions, 08/2018, A5E36770603-AC
8.3
Electromagnetic compatibility
The HMI device satisfies, among other things, the requirements of the EMC guidelines of the
European domestic market.
EMC-compatible installation of the HMI device
The EMC-compliant installation of the HMI device and the application of interference-proof
cable is the basis for interference-free operation.
Observed the following manuals in addition to these operating instructions:
● Designing interference-free controllers
(https://support.industry.siemens.com/cs/ww/en/view/59193566
)
● Industrial Ethernet / PROFINET - Passive network components
(https://support.industry.siemens.com/cs/ww/en/view/84922825
)
● PROFIBUS networks (https://support.industry.siemens.com/cs/ww/en/view/1971286)
Pulse-shaped disturbance
The following table shows the electromagnetic compatibility of modules with regard to pulse-
shaped interference. The precondition for electromagnetic compatibility is that the HMI
device meets the specifications and guidelines for electrical installation.
Pulse-shaped interference
Tested with
Degree of
severity
Electrostatic discharge in
accordance with IEC 61000-4-2
Air discharge: 8 KV
Contact discharge: 6 kV
3
Burst pulses (high-speed
transient interference) in
accordance with IEC 61000-4-4
2 KV signal cable with 24 V DC
2 KV signal/data cable > 30 m
1 KV signal cable < 30 m
3
High-energy single pulse
(surge) in accordance with
IEC 61000-4-5
1
Asymmetrical coupling:
• 2 kV power cable
DC voltage with protective elements
• 2 kV signal cable/data cable > 30 m,
with protective elements as required
Symmetrical coupling:
• 1 kV power cable
DC voltage with protective elements
• 1 kV signal cable > 30 m,
with protective elements as required
3
1
External protective circuit required, see Function Manual "Designing Interference-free Controllers",
section 7 "Lightning and overvoltage protection"
You can find the Function Manual "Designing interference-free controllers" for download on
the Internet (https://support.industry.siemens.com/cs/ww/en/view/59193566
).
