Mounting and connecting the device
3.3 Connecting the device
Comfort Panels
58 Operating Instructions, 08/2018, A5E36770603-AC
Function test
Perform a function test following commissioning. The HMI device is fully functional when one
of the following states is indicated:
● The "Transfer" dialog is displayed.
● The Start Center is displayed.
● A project is started.
Switching off the HMI device
1. Close the project on the HMI device.
2. Switch off the power supply.
See also
Parameterizing Transfer (Page 96)
3.3.10
Securing the cables
After the power-on test, use cable ties to secure the connected cables to the marked fixing
elements for strain relief.
The figure below shows the fastening components with the TP1500 Comfort V2 device as an
example.
