Technical information
8.6 Information on insulation tests, protection class and degree of protection
Comfort Panels
192 Operating Instructions, 08/2018, A5E36770603-AC
The diagram below shows the extended range for temperature and humidity during
continuous operation based on IEC 60721-3-3 Class 3K3.
The information applies to a device installed in landscape without inclination.
Red: Extended temperature range of 7-15" devices; see section
"Permitted mounting positions (Page 34)".
Information on insulation tests, protection class and degree of
protection
Insulation test
The insulation strength is demonstrated in the type test with the following test voltages in
accordance with IEC 61131-2:
Insulation tested with (type test)
707 V DC to other circuits / to ground
Degree of pollution and overvoltage category
The device meets the following requirements according to IEC 61131-2:
Protection class III according to IEC 61131-2
