Technical information
8.5 Climatic ambient conditions
Comfort Panels
Operating Instructions, 08/2018, A5E36770603-AC
191
8.5.3
Operating conditions
The following information applies to a device installed according to the specifications in these
operating instructions.
The HMI device is designed for weatherproof and stationary operation according to
IEC 60721-3-3.
The device meets the requirements according to IEC 60721-3-3 Class 3K3 with the following
amendments and limitations:
Type of condition
Mounting position
Permitted range
Temperature,
Mounting in landscape
format
Vertical
0 ... 50 °C
1
Inclined, maximum inclination 35° 0 ... 40 °C
Temperature,
Mounting in portrait format
Vertical
0 ... 40 °C
Inclined, maximum inclination 35°
0 ... 35 °C
Atmospheric pressure
2
,
operation elevation
1140 ... 795 hPa, corresponds to an elevation of -1000 to 2000 m
Relative humidity
From 10 ... 90%, no condensation at the rear of the device
Pollutant concentration SO
2
: < 0.5 ppm; relative humidity < 60%,
no condensation at the rear of the device
H
2
S: < 0.1 ppm; relative humidity < 60%,
no condensation at the rear of the device
1
TP1900 Comfort and TP2200 Comfort: 0 ... 45 °C
2
No pressure difference is allowed inside and outside the enclosure / control cabinet
Read the Notes on use (Page 30).
Also observe the climate diagram in the following section and the specifications for the
extended inclination and ambient temperature range; see section
"Permitted mounting positions (Page 34)".
Note
The system components connected to the HMI device, the power supply for example,
must
also be suited to the respective operating conditions.
