Commissioning the device
4.3 Parameterizing the Comfort Panel
Comfort Panels
Operating Instructions, 08/2018, A5E36770603-AC
147
4. Press the "Yes" button.
Note
There is no message whether a storage medium is inserted / not inserted.
An automatic restart is carried out.
Applications
We differentiate between the following different cases, depending on whether the system
memory card was previously used for automatic backup:
Using the system memory card without automatically backed up data
1. In the "Service & Commissioning" dialog, "Automatic Backup" tab, check whether the
"Automatic Backup" function is enabled.
– If the function is enabled, close the dialog.
– If the function is not enabled, press the "Enable & Reboot" button.
2. Insert the SIMATIC HMI Memory Card without automatic backup into the slot for the
system memory card.
If the system memory card was recognized and read, the "Use system card" dialog is
displayed as follows:
3. Press the "Continue" button. The device copies the data that is required for the
"Automatic Backup" function onto the system memory card.
The "Automatic Backup" function is then available.
Using system memory card with automatically backed up data, no project data on the HMI
device
1. In the "Service & Commissioning" dialog, "Automatic Backup" tab, check whether the
"Automatic Backup" function is enabled.
– If the function is enabled, close the dialog.
– If the function is not enabled, press the "Enable & Reboot" button.
2. Insert the SIMATIC HMI Memory Card without automatic backup into the slot for the
system memory card.
