Overview
1.3 Design of the devices
Comfort Panels
Operating Instructions, 08/2018, A5E36770603-AC
17
The figure below shows the rear view of the HMI devices, KP400 Comfort (left) and KTP400
Comfort (right):
Blank space for the nameplate
Slots for SD memory cards - accessible from the device side
Connection for equipotential bonding (ground)
Guides for labeling strips
Bottom view and side view
The figure below shows the bottom view and the side view of the KP400 HMI device:
Cutouts for mounting clips
Slots for SD memory cards
