Technical information
8.8 Technical specifications
Comfort Panels
212 Operating Instructions, 08/2018, A5E36770603-AC
Memory
Comfort HMI devices
KP400
Comfort
KTP400
Comfort
KP700
Comfort
TP700
Comfort
KP900
Comfort
TP900
Comfort
KP1200
Comfort
TP1200
Comfort
Usable memory for
application data
4 MB 12 MB
Usable memory for
recipe data
1
512 KB 2 MB
Additional memory for
options
4 MB 12 MB
Data memory card
2
1 x MMC/SD combination slot
System memory card
2
1 x SD slot
1
Can be extended via memory card
2
Memory cards are available as SIMATIC HMI accessories
Interfaces
Comfort HMI devices
KP400
Comfort
KTP400
Comfort
KP700
Comfort
TP700
Comfort
KP900
Comfort
TP900
Comfort
KP1200
Comfort
TP1200
Comfort
1 x RS 422/485 (PROFIBUS)
Max. 12 Mbps, applies to DP operations
Ethernet (PROFINET) 1 x RJ45
10/100 Mbps
2 x RJ45 10/100 Mbps
1
Audio
-
Line Out
USB 2.0 1 x Host
2
1 x Device
3
2 x Host
2
1 x Device
3
1
With integrated switch (one IP address only)
2
USB type A, maximum load 500 mA, equivalent to USB standard 2.0
3
USB type Mini-B (5-pin), equivalent to USB standard 2.0
Power supply
Comfort HMI devices
KP400
Comfort
KTP400
Comfort
KP700
Comfort
TP700
Comfort
KP900
Comfort
TP900
Comfort
KP1200
Comfort
TP1200
Comfort
Rated voltage
Permitted voltage range
24 V DC
+19.2 V to +28.8 V
Rated current 0.13 A 0.5 A 0.75 A 0.85 A
Rated current, load-
dependent
0.13 ... 0.55 A 0.5 ... 0.85 A 0.75 ... 1.05 A 0.85 A ... 1.20 A
Inrush current I
2
t 0.5 A
2
s
Power consumption
1
3.1 W
12 W
18 W
20 W
Maximum permitted transient
35 V (500 ms)
Minimum time between two
transients
50 s
Internal protection
Yes
1
The power loss generally corresponds to the specified value for power consumption.
