Preface
Comfort Panels
6 Operating Instructions, 08/2018, A5E36770603-AC
Term
Applies to
Comfort V2 devices
• KP1500 Comfort, MLFB
6AV2124-1QC02-0AX1
• TP1500 Comfort, MLFB
6AV2124-0QC02-0AX1
• TP1900 Comfort, MLFB
6AV2124-0UC02-0AX1
• TP2200 Comfort, MLFB
6AV2124-0XC02-0AX1
WinCC
1
WinCC V11 (TIA Portal) or
higher for configuring
devices of 12" and smaller
WinCC V11 SP2
HSP Comfort
(TIA Portal) or higher
for configuring
Comfort V1 devices as
of 15"
WinCC V14 SP1
HSP 0211 HMI TP1500
- TP2200 Comfort
(TIA Portal) or higher for
configuring Comfort V2
devices as of 15"
1
Devices are configurable as of WinCC V11. The description in this manual relates to V14 or
higher.
2
You can find the F-State (functional status) on the rating plate of the HMI device.
Features of the various device versions:
● Comfort V1: Display sizes 4"...22", with audio double socket and USB socket type Mini-B,
Windows CE 6 operating system
● Comfort V1.1: Display sizes 7"...12", with audio OUT and USB socket type Mini-B,
Windows CE 6 operating system
● Comfort V2: Display sizes 15"...22", with audio OUT without USB socket type Mini-B,
Windows Embedded Compact 2013 operating system
Figures
This manual contains figures of the described devices. The figures can deviate from the
particularities of the delivered device.
Picture components are marked with black position numbers on a white background
①, ②, ③, etc.
Steps in the figures are identified with white process numbers on a black background
according to the sequence in which they have to be executed: , , , ...
