Technical information
7.5 Technical specifications
Industrial Flat Panel IFP1500, IFP1900, IFP2200, IFP1900 PRO, IFP2200 PRO, IFP1900 ETH, IFP2200 ETH
Operating Instructions, 07/2016, A5E31298376-AF
103
Testing mechanical ambient conditions
The table below provides information on the type and scope of tests for mechanical ambient
conditions.
Vibrations Vibration test in accordance
with IEC 60068, part 2-6
(sinusoidal)
Type of vibration:
Frequency cycles at a rate of change of 1 octave/minute.
5 Hz ≤ f ≤ 8.4 Hz, constant amplitude 3.5 mm
8.4 Hz ≤ f ≤ 200 Hz, constant acceleration 1 g
Vibration duration:
10 frequency cycles per axis in each of the three
Shock Shock test in accordance
with IEC 60068, Part 2-27
Severity of shock:
Peak value 15 g, duration 11 ms
Direction of shock:
3 shocks in ± direction of axis in each of the three axes
Climatic ambient conditions
The following table shows the climatic ambient conditions for operation of the device.
Temperature built-in units:
• Vertical mounting
0 ... 50 °C (landscape format)
1
0 ... 40 °C (portrait format)
• Mounting at an angle
0 ... 40 °C (landscape format)
0 ... 35 °C (portrait format)
Slope angle max. 35°
• Vertical mounting
0 ... 45 °C (landscape format)
• Inclined mounting
0 ... 45 °C (landscape format) Tilt angle max. 45°
10 ... 90%, without condensation
Atmospheric pressure 1 080 to 795 hPa Corresponds to an elevation
Pollutant concentration SO
2
: < 0.5 vpm;
Relative humidity <60%,
Test: 10 cm
3
/m
3
; 10 days
H
2
S: < 0.1 vpm;
Relative humidity <60%,
no condensation
Test: 1 cm
3
/m
3
; 10 days
1
IFP1900 and IFP2200: From 0 to 45° C
