Installing and connecting the device
3.3 Mounting the PRO device
Industrial Flat Panel IFP1500, IFP1900, IFP2200, IFP1900 PRO, IFP2200 PRO, IFP1900 ETH, IFP2200 ETH
Operating Instructions, 07/2016, A5E31298376-AF
47
PRO devices, suitable for support arm / pedestal and extension components
Note
Mounting with and without a base adapter
The SIMATIC PRO devices are designed for mounting with the base adapter. If you install
the device without a base adapter, you must adjust the mechanica
l interface between the
support arm or pedestal and the unit accordingly, including placement of an appropriate seal
on the mechanical interface.
● All packaging components and protective films have been removed.
● Siemens base adapter with screws.
● One of the following support arms or pedestal systems:
– Support arm or pedestal with mechanical VESA interface and the corresponding
Siemens adapter set
– Support arm or pedestal with mechanical interface suitable for the Siemens base
adapter
See also section "System components for PRO devices (Page 24)".
● The following cables are fed through the pedestal or the support arm to which the device
is mounted:
– Protective conductor
– Power supply cable
– Data cables, e.g. USB, DVI and DisplayPort connecting cable
Recommendation: Route large connectors, for example DVI or PROFIBUS, and their
cables through the pedestal or support arm first.
This section describes how to install the device to a support arm system. Installation on a
pedestal is carried out in the same way. For devices of the type "suitable for support arm",
the base adapter is screwed to the device from the top; for devices of the type "suitable for
pedestal", it is screwed from below. A device for a support arm system cannot be used on a
pedestal, and vice versa.
