Configuring with Web Based Management
5.6 "Interfaces" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
181
On this page, you specify the configuration for the access point.
Note
This tab is available only in access point mode.
Table 1 has the following columns:
●
Shows the available WLAN interfaces in this column.
●
Specify the main channel.
If you want the access point to search for a free channel itself, use "Auto". The selection
of channels used by an access point when establishing a wireless cell can be restricted.
To do this, select the "Use Allowed Channels only" check box on the Allowed Channels"
tab.
.If you want to use a fixed channel, select the required channel from the drop-down list.
