Commissioning
7.4 Notes on operation
SIMATIC Rack PC 547B
44 Operating Instructions, 12/2007, A5E01127519-02
The table and information below apply only to the delivery state of the device, in other words,
no changes or expansions have been made.
RAID BIOS RAID software SATA interface Installation location Enclosure labeling
Port 0 Device Port 0 SATA1 (1) Removable
cartridge 1
1
Port 2 Device Port 2 SATA3 (2) Removable
cartridge 2
2
Port 0 Device Port 0 SATA1 (3) Side panel 1 1
Port 2 Device Port 2 SATA3 (4) Side panel 2 2
Please replace the faulty drive with a new one of the same type and capacity.
