Programming via SIMATIC controller
8.4 General structure of the function blocks
SIMATIC RF650R/RF680R/RF685R
116 Configuration Manual, 03/2018, C79000-G8976-C386-06
Description of the parameters
Table 8- 2 Description of the input and output parameters
EN Enabling Input
EXECUTE There must be a positive edge at this input before the block will exe-
HW_CONNECT Global parameter of the type "IID_HW_CONNECT" to address the
channel/reader and to synchronize the blocks. This parameter needs
to be created and addressed once for each channel/reader.
"HW_CONNECT" must always be transferred to the blocks to ad-
dress the relevant channel/reader.
The job was executed. If the result is positive, this parameter is set.
ERROR (BOOL) The job was ended with an error. The error code is indicated in Sta-
The job is being executed.
Display of the error message if the "ERROR" bit was set.
PRESENCE (BOOL) This bit indicates the presence of a transponder. The displayed value
is updated each time the block is called. This parameter does not
exist in blocks specific to optical reader systems.
General sequence when calling the blocks
Note
Different sequences with the Ident profile and standard profile V1.19
Note that the sequence of the Ident profile is not the same as
that of the previous standard
profile V1.19. Standard profile V1.19 is not compatible with the RF600 readers.
