Programming via SIMATIC controller
8.6 Programming the Ident profile
SIMATIC RF650R/RF680R/RF685R
144 Configuration Manual, 03/2018, C79000-G8976-C386-06
Table 8- 28 LOCK-TAG-BANK
CMD
EPCID_
UID
LEN_ID
PSWD
LOCK_TAG_BANK_
ACTION
LOCK_TAG_BANK_
MASK
IDENT_DATA
0x79 EPC ID
0x00 ≙ un-
specified
single tag
access
Length of the
EPC-ID (2-62
bytes)
0x00 ≙ un-
specified
single tag
access
Password
0x00 ≙ no
password
For a detailed de-
scription of the pa-
rameters, refer to
the section
"lockTagBank
(Page 258)" or the
"EPC specification".
For a detailed de-
scription of the pa-
rameters, refer to
the section
"lockTagBank
(Page 258)" or the
"EPC specification".
--
Table 8- 29 EDIT-BLACKLIST
CMD
EDIT_
BLACKLIST_MODE
EPCID_
UID
LEN_ID
IDENT_DATA
0x7A
• 0x00 ≙ add EPC-ID
• 0x01 ≙ add all "OBSERVED"
transponders
• 0x02 ≙ delete EPC-ID
• 0x03 ≙ delete all
EPC ID Length of the EPC-ID (2-
62 bytes)
--
In the section "Filtering out transponders using the "Black list" (Page 325)" you will find a
description of how the "Black List" works based on an example.
Table 8- 30 GET-BLACKLIST
CMD
OFFSETBUFFER
IDENT_DATA
0x6C
Offset in the "RXREF" receive buffer
Read black list IDs
Table 8- 31 Result of GET-BLACKLIST
Name
Type
Comment
NUM IDS
WORD
Number of MDS
TAG_DATA
ARRAY[1..n] of
IID IN I 80
TAG_DATA[1]
IID_IN_I_80
Reserved
BYTE
ID_Len
BYTE
Length of EPC ID
EPC_ID
ARRAY[1..62] of
BYTE
EPC-ID
TAG_DATA[2]
IID_IN_I_80
...
...
TAG_DATA[n]
IID_IN_I_80
