Siemens SIMATIC RF650R User Manual

Description
3.1 Properties of the UHF readers
SIMATIC RF650R/RF680R/RF685R
16 Configuration Manual, 03/2018, C79000-G8976-C386-06
Characteristics
The following characteristics distinguish the SIMATIC RF650R, RF680R and RF685R UHF
readers:
Table 3- 1 Characteristics of the readers
Characteristics
RF650R
RF680R
RF685R
Antennas 4 x external antenna connectors 1 x internal, adaptive
antenna
1 x external antenna
connector
Transmit power (max.)
4000 mW
1)
Digital inputs/outputs
4 x digital inputs and 4 x digital outputs
RS-422 interface
--
1 x plug M12 8-pin
PROFIBUS connection
via CM
-- ASM 456
(115.2 kbps)
Ethernet interface 1 x Industrial Ethernet,
RJ-45
2 x Industrial Ethernet, M12
Transmission speed
(max.)
100 Mbps 100 Mbps
Degree of protection
IP30
IP65
Configura-
tion/diagnostics options
WBM (browser) WBM (browser)
STEP 7 (S7)
Interfaces to
PC/controller
XML interface
(TCP/IP with XML pro-
tocol)
XML interface
SIMATIC interface
(TCP/IP with XML protocol, OPC UA, Ethernet/IP
or PROFINET capability)
1)
The maximum transmit power is restricted depending on the country of use.
NOTICE
IRT is not supported
Note that the RF680R/RF685R readers do not support IRT (Isochronous Real Time). The
readers can also not function as IRT conductors (e.g. in a bus structure).
The readers can be configured as clients in MRP rings. Network diagnostics via SNMP is
supported by the readers.
NOTICE
Operation in VLANs
Note that the readers cannot be operated in VLANs whose ID is ≠ 0.
