Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
264 Configuration Manual, 03/2018, C79000-G8976-C386-06
value_id Decimal value
0...4294967295 Unique command identifier
value_resultCode Decimal value
0...9
0...65535 Identification number of the error
You will find a list of possible return
codes in the following table.
value_name Text -- Textual description of the error
You will find descriptions of the prob-
lems in the following table.
value_cause Text -- Brief description of the cause of the
List of possible result codes
0x00 0 NO_ERROR Positive reply, command processed suc-
0x13 19 ERROR_MEMORY_OVERRUN Access outside the addressed memory
0x1A 26 ERROR_TAG_LOCKED The transponder to which data is meant to
be written or which should be deactivated is
The transponder is not responding.
0x92 146 ERROR_WRONG_PASSWORD The password you entered is incorrect.
Access to the transponder was denied.
Verification of the transponder failed.
General transponder error.
0x95 149 ERROR_TAG_INSUFFICIENT_
There is not enough transponder power.
0x22 34 ERROR_TOO_MANY_TAGS There are too many transponders in the
0xA1 161 ERROR_NO_TAG There is no transponder with the relevant
EPC-ID in the antenna field.
The requested data is not available.
No radio channel activated.
No carrier signal activated.
0xA7 167 ERROR_MORE_THAN_ONE_
There is more than one transponder in the
0xA8 168 ERROR_AIR_PROTOCOL_
General radio protocol error
