Programming via XML interface
10.4 XML EventReports
SIMATIC RF650R/RF680R/RF685R
276 Configuration Manual, 03/2018, C79000-G8976-C386-06
0x1599 5529 ERROR_WRONG_TYPE_OR_VERSION_ANTENNA_1
Wrong antenna type or wrong antenna version at connector ANT 1.
0x159A 5530 ERROR_WRONG_TYPE_OR_VERSION_ANTENNA_2
Wrong antenna type or wrong antenna version at connector ANT 2.
0x159B 5531 ERROR_WRONG_TYPE_OR_VERSION_ANTENNA_3
Wrong antenna type or wrong antenna version at connector ANT 3.
0x159C 5532 ERROR_WRONG_TYPE_OR_VERSION_ANTENNA_4
Wrong antenna type or wrong antenna version at connector ANT 4.
0x1567 5479 ERROR_READ_COMMAND_FAILED
0x1591 5521 Antenna error at connector ANT 1
You can find additional information on antenna errors and possible solutions in
the section "XML/PLC error messages (Page 290)".
Antenna error at connector ANT 2
Antenna error at connector ANT 3
Antenna error at connector ANT 4
0x7B71 31601 "Overflow - Alarms": Send buffer for "Alarms" is full. Alarm messages can be
discarded until the next "alarm" is received.
0x7B73 31603 "Overflow - TagEventReports": Send buffer for "TagEventReports" is full. Data
can be lost until the next "TagEventReport" is received.
0x9BFD 39933 ERROR_PARAMETER_INVALID_VALUE
A parameter has an invalid value.
0x9CC5 40133 ERROR_ANTENNA
An antenna error was detected when executing the command.
You can find additional information on antenna errors and possible solutions in
the section "XML/PLC error messages (Page 290)".
Power supply error. The power supply is very close to the low limit.
0x9D8E 40334 ERROR_TOO_MANY_TAGS
There are too many transponders in the antenna field.
0x9DF1 40433 ERROR_MEMORY_OVERRUN
Access outside the addressed memory area.
0x9DEA 40426 ERROR_TAG_LOCKED
The transponder to which data is meant to be written or which should be deac-
Connection attempt failed.
Configuration successfully loaded.
