Service and maintenance
12.2 Error messages
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
293
Invalid data block number (DBN) on the reader/communications module
-- 0x55 0xE5FE05 Invalid data block number (DBN) in the Ident profile
Invalid data block length (DBL) on the reader/communications module
Invalid data block length (DBL) in the Ident profile
2 Hz 0x58 0xE5FE08 The previous command is still active or the buffer is full.
A new command was sent to the reader or communications module although the last com-
mand is still active.
• The active command can only be aborted with "INIT".
• Before a new command can be started, "DONE bit = 1" must be set (exception: "INIT").
• Two Ident profile calls had the same "HW_ID", "CM_CHANNEL" and "LADDR" parame-
ter settings.
• Two Ident profile calls are using the same pointer.
• After eliminating the error, an "INIT" must be executed.
• When working with command repetition (e.g., fixed code transponder), no data is being
fetched from the transponder. The data buffer on the reader/communications module
has overflowed. Transponder data has been lost.
-- 0x59 0xE5FE09 The reader/communications module runs a hardware reset ("INIT_ACTIVE" set to "1"). The
Ident profile expects an "INIT" (bit 15 in the cyclic control word).
-- 0x5A 0xE5FE0A The "CMD" command code and the relevant acknowledgement do not match. This can be a
software error or synchronization error that cannot occur in normal operation.
Incorrect sequence of acknowledgement frames (TDB / DBN)
-- 0x5C 0xE5FE0C Synchronization error (incorrect increment of AC_H / AC_L and CC_H / CC_L in the cyclic
control word). "INIT" had to be executed.
-- -- 0xE5FE81 Communications error between reader and communications module
-- -- 0xE5FE82 Communications error between reader and communications module
-- -- 0xE5FE83 Communications error between reader and communications module
Functional error of the serial interface
-- -- 0xE5FE84 Communications error between reader and communications module
2 Hz 0x61 0xE6FE01 Unknown command
An uninterpretable XML command was sent to the reader or the Ident profile sends an
uninterpretable command to the reader.
Possible causes:
• The "AdvancedCmd" block was supplied with an incorrect "CMD".
• The "CMD" input of the "AdvancedCmd" block was overwritten.
Invalid command index (CI)
