Siemens SIMATIC RF650R User Manual

Service and maintenance
12.2 Error messages
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
295
"ER"
LED
XML/
LED
(hex)
PLC block
(hex)
Error description
-- 0x65 0xE6FE05 An error has occurred that makes a Reset_Reader ("WRITE-CONFIG" with "Config = 3")
necessary.
Possible causes / action to be taken:
• The "WRITE-CONFIG" command is incorrect.
• After eliminating the error, execute an "INIT".
• Check the "IID_HW_CONNECT" parameter.
-- 0x66 0xE6FE06 The reset timer has expired.
2 Hz
0xE1
0xE6FE81
A parameter is missing.
2 Hz
0xE2
0xE6FE82
The parameter has an invalid format.
2 Hz
0xE3
0xE6FE83
The parameter type is invalid.
2 Hz
0xE4
0xE6FE84
Unknown parameter.
2 Hz
0xE5
0xE6FE85
The command or the frame has an invalid format.
2 Hz
0xE6
0xE6FE86
The inventory command failed.
2 Hz
0xE7
0xE6FE87
Read access to the transponder has failed.
2 Hz
0xE8
0xE6FE88
Write access to the transponder has failed.
2 Hz
0xE9
0xE6FE89
Writing the EPC-ID on the transponder has failed.
2 Hz
0xEA
0xE6FE8A
Enabling write protection on the transponder has failed.
2 Hz
0xEB
0xE6FE8B
The "Kill" command failed.
2 Hz
0x71
0xE7FE01
In this status, only the "Reset_Reader" command ("WRITE-CONFIG") is permitted.
--
0x72
0xE7FE02
The "CMD" command code is not permitted.
-- 0x73 0xE7FE03 The "LEN_DATA" parameter of the command is too long and does not match the global
data reserved within the send data buffer (TXBUF).
-- 0x74 0xE7FE04 The receive data buffer (RXBUF) or the send data buffer (TXBUF) is too small, the buffer
created at TXBUF/RXBUF does not have the correct data types or the parameter
"LEN_DATA" as a negative value.
Possible cause / action to be taken:
• Check whether the buffers TXBUF/RXBUF are at least as large as specified in
LEN_DATA.
• With S7-1200/1500:
– In the Ident profile, only an "Array of Byte" may be created for TXBUF and RXBUF.
– In the "Reader_Status" block, only an "Array of Byte" or the corresponding data
types ("IID_TAG_STATUS_XX_XXX" or "IID_READER_STATUS_XX_XXX") may be
created
-- 0x75 0xE7FE05 Error message that informs you that only an "INIT" command is permitted as the next com-
mand. All other commands are rejected.
-- 0x76 0xE7FE06 Wrong index
Permitted index is in the ranges "101 ... 108" and "-20401 ... -20418".
-- 0x77 0xE7FE07 The reader or communications module does not respond to "INIT" ("INIT_ACTIVE" is ex-
pected in the cyclic status message).
The next steps:
• Check the address parameter "LADDR".
--
0x78
0xE7FE08
Timeout during "INIT" (60 seconds according to "TC3WG9")
