Configuring with the WBM
7.2 The WBM
SIMATIC RF650R/RF680R/RF685R
46 Configuration Manual, 03/2018, C79000-G8976-C386-06
At the left top edge of the WBM there is a the login and menu tree. Below the login/logout
area, there are various menu items. The currently selected menu item is highlighted in dark
blue.
The following table provides an overview of the menu items and the functions they provide.
Table 7- 2 The menu structure of the WBM
Start page
• System overview
• Viewing device-specific information
• Entering customer-specific plant designation
General
• Selecting a country profile and channels
• Enabling/disabling categories of log events
Read points
• Defining read points and assigning antennas
• Specifying antenna parameters
• Setting algorithms to improve reading quality
• Assigning tag fields
• Assigning filters
• Setting triggers
Tag fields
• Creating and editing tag fields
Filters
• Creating and editing filters
Digital outputs
• Setting the behavior of the digital outputs
Communication
• Making communications settings
Adjust antennas
• Optimization of the antenna alignment
Activation power
• Detect activation power
Tag monitor
• Displaying the read quality
• Overview of the identified transponders
• Display of the digital inputs/outputs
Log
• Overview of the log entries
Messages
• Overview of the messages of the WBM
Edit transponder
• Changing EPC-IDs
• Reading out transponder data and writing to tag fields
• Locking transponder access
• 'Destroying' transponders
