Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
53
Log settings
In the "Log settings" area, you can use the check boxes to decide which events are entered
in the log. The log is structured as a circular buffer. Bear in mind that with a high degree of
detail of the data, the circular buffer fills up more quickly which can have a negative effect on
the performance of the device.
Table 7- 4 Description of the parameters of the log
Parameter
Description
General
COMMON Messages relating to general events:
e.g. reader startup, login to the WBM, ...
ERRORS
Error and alarm messages of the reader
GPIO Changes to the digital inputs/outputs
FILTER
Transponders that were filtered out.
COMMANDS
Commands of the user application
EVENTS
Recording of all tag events (e.g. glimpsed, ...)
Additional information
Return value Return values for the commands of the user application and for the written or
read transponder data.
Call parameters
Call parameters for the commands of the user application
Extended acquired
values
Additional data obtained when the transponder was identified (antenna, polari-
zation, channel, ...).
Reader status com-
mands
Recording reader status commands in PLC communication. Can be switched
off if the reader status commands are used as cable monitoring. In this way,
the logbook is kept free for user data.
Internal heartbeat
telegrams
Recording heartbeat telegrams in the service information. In this way, the
logbook is kept free for user data.
Service information
CMD_XML Frames on the XML interface
CMD_PLC
Internal frames on the PLC interface
CMD_WEB
Internal frames between Web server and reader
UHF_LOGIC
Internal frames to the UHF part of the reader
