Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
64 Configuration Manual, 03/2018, C79000-G8976-C386-06
In the "Tag fields" area, you can assign tag fields to a read point. Tag fields are logical
memory areas of a transponder that have symbolic names. To read out the tag fields from
every transponder automatically, these must be assigned to the read points. This additional
data is sent along with the "TagEventReports" via the XML interface.
The content of the tag fields is output only via the tag events (Page 266) of the XML
commands.
Table 7- 7 Description of functions
Assign tag field
Click the button to assign existing tag fields to the read point. You can select the re-
quired tag field from the drop-down list.
Create new tag field
Click the button to create new tag fields. The button acts as a link to the "Settings -
Tag fields" menu item.
Delete tag field
Click the button to remove tag fields already assigned to the read point.
Edit tag field
Click the button to edit existing tag fields. The button acts as a link to the "Settings -
You will find more information on the tag fields in the section "The "Settings - Tag fields"
menu item (Page 66)".
In the "Filters" area, you can assign filters to the read point. The data required for the
comparison with the filter criteria is read out after reliable identification of a transponder.
Depending on the filter evaluation (criterion applies / does not apply), identified transponders
are either filtered out or not.
Table 7- 8 Description of functions
Assign filter
Click the button to assign existing filters fields to the read point. You can select the
required filter from the drop-down list.
Create new filter
Click the button to create new filters. The button acts as a link to the "Settings - Fil-
Remove filters
Click the button to remove filters already assigned to the read point.
Edit filters
Click the button to edit existing filters. The button acts as a link to the "Settings - Fil-
