Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
65
You will find more information on filters in the section "The "Settings - Filters" menu item
(Page 68)".
In the "Trigger" area, you can specify the conditions that will trigger inventories. If a Inventory
Power Ramp was configured, this is fired by triggers. If one of the assigned conditions
applies, inventories are taken. With "Trigger action" you can set whether the response to the
trigger is that
● a specified/permanent number of inventories is taken or
● inventories are taken for a specified/permanent time [ms].
These conditions are also used with the XML command "triggerSource".
If you do not specify a trigger, you can trigger inventories using the corresponding XML
commands ("triggerSource") or SIMATIC blocks ("Inventory", "Read_xxx") or XML
commands ("Scan"). Note that configuring triggers is unnecessary for operation using S7.
Click the button
to specify up to two conditions. Click the button to remove already
specified conditions.
Table 7- 9 Description of the trigger conditions
IO_LEVEL With this condition, the reader continues to take inventories uninterrupted
as long as the selected input/output is in the specified state "On" or "Off".
IO_EDGE With this condition, the reader takes inventories once as set in "Trigger
action". When there is an edge change at the selected input.
With this condition, the reader takes inventories continuously.
TIMER With this condition, the reader takes inventories as set in "Trigger action".
Following this, there is a pause with the value set in the "TIMER" box [ms].
