Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
78 Configuration Manual, 03/2018, C79000-G8976-C386-06
Tag events / tag commands
Tag events signal identified transponders or when they have left the antenna field.
Information on all activated tag events is reported by the reader to the XML API interface.
The triggers for messages are the following event types:
● Glimpsed
Transponder was scanned the first time.
● Observed
The transponder was identified reliably for at least "x" read cycles. You can set the
number "x" in the section "The "Settings - Read points" menu item (Page 54)" in the area
"Algorithmen > Smoothing > Observed Count" (default value = 1).
● Lost
The transponder was no longer identified reliably for at least "x" read cycles. You can set
the number "x" in the section "The "Settings - Read points" menu item (Page 54)" in the
area "Algorithmen> Smoothing Lost Count" (default value = 5).
Note that with the events, only the activated data of the transponder is reported.
The data enabled in this area also affects the message content of the XML commands/reply
frames (e.g. with "writeTagID").
Table 7- 17 Description of the event data "Tag events / Tag commands"
Data
Description
event
Event type / status description of the transponder (Glimpsed, Observed, Lost)
utcTime Time of the event
antennaName
Name of the antenna that scanned the transponder.
rSSI
Signal strength of the transponder
rSSIMin
Minimum signal strength of the transponder
rSSIMax
Maximum signal strength of the transponder
power
Radiated power of the antenna at the time of the scan
tagPC Protocol Control Word
You will find further information in the "EPCglobal Specifications".
channel
Active send channel at the time of the identification
airRetry
Number of command repetitions on the air interface
commandRetry
Number of command repetitions
filterDataAvailable Information as to whether the data to be used for filtering could be read from
the transponder.
inventoried
Number of identifications of a transponder
polarization
Polarization of the antenna at the time of the scan
Not every XML command/event report provides information about all the data activated here.
You will find information indicating which XML commands/event reports provide data in the
sections "XML commands (Page 191)" and "XML EventReports (Page 266)".
