S5-115F Manual STEP 5 Operations
Processing an arithmetic operation
Before an arithmetic operation is executed, both operands must be loaded into the accumulators.
Note
When using arithmetic operations, make sure the operands have the same number
format.
Arithmetic operations are executed independently of the RLO. The result is available in ACCUM 1
for further processing. The contents of ACCUM 2 are not changed. These operations do not affect
the RLO. The condition codes are set according to the results.
