S5-115F Manual Configuring with COM 115F
1.1.7 F7: System Handling
Press softkey F7 to display the ”System Handling” menu ( Figure 1-14).
Figure 1-14. System Handling
PROGRAM FILE: A:@@@@@@ST.S5D
F1 CONF DIR : Configuration DB directory
F2 DEL DB : Delete DB
F3 TRAN/LOAD : Transfer/Load
F4 PRINT : Print
F5 PRG-DAT : Change program file names
F6 :
F7 AUX : Call STEP 5 auxiliary functions
F8 RETURN : Return to previous menu
