Configuring with COM 115F S5-115F Manual
F3 Master coordination byte
Figure 1-9 will appear if you have entered a master in the SINEC L1 Interface screen form. You
can enter the following:
Master coordination byte Receive B
Master coordination byte Send B
Master coordination byte Receive A (redundant LAN only)
Master coordination byte Send A (redundant LAN only)
Figure 1-9. Screen Form for SINEC L1 Master Coordination Bytes (Example)
COORD BYTE RECEIVE A DB or flag (D/F): D
DB No. (4 to 255): 45
DB word No. (0 to 255): 1
COORD BYTE SEND A DB or flag (D/F): D
DB No. (4 to 255): 45
DB word No. (0 to 255): 2
COORD BYTE RECEIVE B DB or flag (D/F): D
DB No. (4 to 255): 45
DB word No. (0 to 255): 3
COORD BYTE SEND B DB or flag (D/F): D
DB No. (4 to 255): 45
DB word No. (0 to 255): 4
F8
RETURN
F7
SINEC L1 Master Coordination Bytes COM 115F / PDC15
F1 F2 F3 F4 F5 F6
SAVE
