Configuring with COM 115F S5-115F Manual
Table 1-9. EPROM Function Error Messages
No. Error Text
101
H
102
H
103
H
104
H
105
H
106
H
107
H
108
H
109
H
10A
H
10B
H
10C
H
10D
H
10E
H
10F
H
110
H
111
H
112
H
113
H
114
H
115
H
116
H
117
H
118
H
119
H
11A
H
11B
H
11C
H
11D
H
EPROM HAS NO IDENTIFIER
RESULT OF COMPARISON NOT EQUAL
INVALID EPROM CONTENTS
WRONG MODE
WRONG FRAME LENGTH
WRONG SCREEN LINE
WRONG SCREEN COLUMN
ILLEGAL PROGRAMMER NUMBER
UNKNOWN EPROM
EPROM NOT ERASED
NO EEPROM
WRONG DISKETTE
ERROR IN FILE
HARDWARE ERROR
ERROR IN DISKETTE/DRIVE
EMPTY EPROM
DUPLICATED BLOCK
DIRECTORY OVERFLOW
DRIVER CALL UNSUCCESSFUL
BLOCK NOT AVAILABLE
BLOCK ALREADY EXISTS
TYPE NOT IN DIRECTORY
ILLEGAL CALL
DIRECTORY FULL
ILLEGAL SYS-ID WRITE
SUBMODULE NOT PROVIDED
SYS-ID NOT FOUND
BUFFER TOO SMALL
SYS-ID BLOCK WRITE FORBIDDEN
