STEP 5 Operations Manual S5-115F
Total length
max. 143 words (with 0 parameters)
max. 146 words (with 1 parameter)
:
max. 263 words (with 40 parameters)
FB Header 5 W
LPLZ incrementation sequence 5 W
User operations: max. 127 W
BE 1 W
Parameter list: 3 words, 6 characters/ max. 40 parameters
parameter:
max. 120 W
Skip name and parameter list 1 W
Block name 4 W
Figure 3-6. Construction of a Single-Segment-FB for Parameters and Operations
Figure 3-7. Structure of a Multi-Segment FB (max. 4096 words)
BE in last segment instead of BLD 255 1 W
FB Header: 5 W
LPLZ incrementation sequence 5 W
User operations: max. 127 W
BLD 255 operations 1 W
LPLZ incrementation sequence 5 W
User operations: max. 127 W
BLD 255 operations 1 W
Parameter list: 3 words, 6 characters/ max. 40 parameters
parameter:
max. 120 W
Skip name and parameter list 1 W
Block name 4 W
3-40 EWA 4NEB 811 6149-02
