S5-115F Manual Configuring with COM 115F
Only the configuration DBs of a logical device (PLC, FD or EPROM) can be printed out, i.e. the
configuration must be available on the relevant device. The footer can also be printed out.
The following functions will be executed if you press F1 to F6:
F1 The whole configuration is printed out (F2+F3). Comprehensive documentation is
generated.
F2 This function can be used to print out a specific I/O type. After the type has been selected, all
the inputs of this type are printed out. This takes the form of a table of the I/O modules
( Figure 1-36). The short text is printed from the plaintext line. When you press the F6 key,
the prompt
”ENTER TYPE NO.”
will appear in the command line. The system then expects input of the type number. When
you press the <CR> key, this entry will be tested for validity and the error message
”WRONG TYPE”
may be displayed, if applicable. If the type is not available, the message
”DB(S) NOT AVAILABLE”
will appear.
If you press <Break>, the function will be aborted.
F3 Print DB1
Use this function to print out DB 1 with information about the operating system, communi-
cations and mailbox table. The parameters are grouped according to function in the print-
out.
F5 Select program file
After pressing the F5 key in the Handling menu, the user can select a program file on the
diskette or hard disk. If the program file is accessed before it has been declared,
B:@@@@@@ST.S5D will be accessed.
F6 Default
The ”Default” menu appears again here ( Figure 1-2).
F7 Auxiliary functions
This key calls the STEP 5 auxiliary functions (overlay file). See your programmer manual for
further details.
EWA 4NEB 811 6149-02
1-53
