Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
A5E37208904-003, 04/2017
109
Par. No.
Name
Unit
Data type
r0945[0...6
3]
Fault code
-
U16
Description: Displays the number of faults that have occurred.
Dependency: Refer to r0949
Note:
The buffer parameters are cyclically updated in the background.
Fault buffer structure (general principle):
r0945[0], r0949[0] → actual fault case, fault 1
...
r0945[7], r0949[7] → actual fault case, fault 8
r0945[8], r0949[8] → 1st acknowledged fault case, fault 1
...
r0945[15], r0949[15] → 1st acknowledged fault case, fault 8
...
r0945[56], r0949[56] → 7th acknowledged fault case, fault 1
...
r0945[63], r0949[63] → 7th acknowledged fault case, fault 8
r0949[0...6
3]
Fault value
-
I32
Description: Displays additional information about the fault that occurred (as integer number).
Dependency: Refer to r0945
Note:
The buffer parameters are cyclically updated in the background.
The structure of the fault buffer and the assignment of the indices is shown in r0945.
r0964[0...6
]
Device identification
-
U16
Description: Displays the device identification.
Index:
• [0]: Company (Siemens = 42)
• [1]: Device type
• [2]: Firmware version
• [3]: Firmware data (year)
• [4]: Firmware data (day/month)
• [5]: Number of drive objects
•
[6]: Firmware patch/hot fix
Note:
Example:
r0964[0] = 42 → SIEMENS
r0964[1] = Device type
r0964[2] = 403 → First part of the firmware version V04.03 (for second part, refer to index 6)
r0964[3] = 2010 → Year 2010
r0964[4] = 1705 → 17th of May
r0964[5] = 2 → 2 drive objects
r0964[6] = 200 → Secnod part, firmware version (complete version: V04.03.02.00)
r0965
PROFIdrive profile number
-
U16
Description:
Displays the PROFIdrive profile and profile version.
Constant value = 0329 hex
Byte 1: Profile number = 03 hex = PROFIdrive profile
Byte 2: Profile version = 29 hex = Version 4.1
Note: When the parameter is read via PROFIdrive, the Octet String 2 data type applies.
