Connecting
4.3 Control/status interface - X8
SINAMICS V90, SIMOTICS S-1FL6
120 Operating Instructions, 04/2019, A5E36037884-007
Pin No.
Signal
Wire color on the set-
point cable exposed
side
Description
15, 16, 40, 41:
Encoder emulation pulse output with high-speed 5 V differential signals (A+/A-, B+/B-)
15 PTOA+ White-Yellow High-speed 5 V differential pulse train en-
coder output A (+)
16 PTOA- Yellow-Brown High-speed 5 V differential pulse train en-
coder output A (-)
40 PTOB+ Gray-Blue High-speed 5 V differential pulse train en-
coder output B (+)
41 PTOB- Pink-Blue High-speed 5 V differential pulse train en-
coder output B (-)
17, 25 *:
Encoder Zero phase pulse output and reference ground (with open collector)
17 PTOZ (OC) White-Gray Pulse train encoder output Z signal (open
collector output)
25 * PTOZ_M (OC) Gray-Green Pulse train output Z signal reference ground
(open collector output)
42, 43:
Encoder Zero phase pulse output with high-speed 5 V differential signals
42 PTOZ+ Gray-Red High-speed 5 V differential pulse train en-
coder output Z (+)
43 PTOZ- Pink-Red High-speed 5 V differential pulse train en-
coder output Z (-)
24 *:
PTO and PTI_D reference ground
24 *
M
Brown-Red
PTO and PTI_D reference ground
Digital inputs/outputs
3
DI_COM
Green
Common terminal for digital inputs
4
DI_COM
Yellow
Common terminal for digital inputs
5
DI1
Gray
Digital input 1
6
DI2
Pink
Digital input 2
7
DI3
Blue
Digital input 3
8
DI4
Red
Digital input 4
9
DI5
Black
Digital input 5
10
DI6
Violet
Digital input 6
11
DI7
White
Digital input 7
12
DI8
Brown
Digital input 8
13
DI9
White-Green
Digital input 9
14
DI10
Brown-Green
Digital input 10
23 Brake White-Red Motor holding brake control signal (for
SINAMICS V90 200 V variant only)
28
P24V_DO
Yellow-Gray
External 24 V supply for digital outputs
29 *
DO4+
Green
Digital output 4+
30 DO1 Yellow Digital output 1
