Siemens SIMOTICS S-1FL6 User Manual

Connecting
4.3 Control/status interface - X8
SINAMICS V90, SIMOTICS S-1FL6
124 Operating Instructions, 04/2019, A5E36037884-007
No.
Name
Type
Description
Control mode
PTI
IPos
S
T
Fast
PTI
8
EGEAR1
Level
Electronic gear.
A combination of the signals EGEAR1 and
EGEAR2 can select four electronic gear ratios.
EGEAR2 : EGEAR1
• 0 : 0: electronic gear ratios 1
• 0 : 1: electronic gear ratios 2
• 1 : 0: electronic gear ratios 3
• 1 : 1: electronic gear ratios 4
✓
X
X
X
✓
9 EGEAR2 Level ✓ X X X ✓
10
TLIM1
Level
Torque limit selection.
A combination of TLIM1 and TLIM2 can select
four torque limit sources (one external torque
limit, three internal torque limits).
TLIM2 : TLIM1
• 0 : 0: internal torque limit 1
• 0 : 1: external torque limit (analog input 2)
• 1 : 0: internal torque limit 2
• 1 : 1: internal torque limit 3
✓ ✓ ✓ X ✓
11 TLIM2 Level
12 CWE Level Enable clockwise rotations.
• 1: Enable clockwise rotation, ramp up
• 0: Disable clockwise rotation, ramp down
X X ✓ ✓ X
13 CCWE Level Enable counter-clockwise rotations.
• 1: Enable counter-clockwise rotation, ramp
down
• 0: Disable counter-clockwise rotation, ramp
up
X X ✓ ✓ X
14 ZSCLAM
P
Level Zero speed clamps.
• 1 = when the motor speed setpoint is an
analog signal and lower than the threshold
level (p29075), the motor is clamped.
• 0 = no action
X X ✓ X X
