Siemens SIMOTICS S-1FL6 User Manual

Connecting
4.3 Control/status interface - X8
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
125
No.
Name
Type
Description
Control mode
PTI
IPos
S
T
Fast
PTI
15
SPD1
Level
Select speed mode: fixed speed setpoint.
A combination of the signals SPD1, SPD2 and
SPD3 can select eight speed setpoint sources
(one external speed setpoint, seven fixed
speed setpoints).
SPD3 : SPD2 : SPD1
• 0 : 0 : 0: external analog speed setpoint
• 0 : 0 : 1: fixed speed setpoint 1
• 0 : 1 : 0: fixed speed setpoint 2
• 0 : 1 : 1: fixed speed setpoint 3
• 1 : 0 : 0: fixed speed setpoint 4
• 1 : 0 : 1: fixed speed setpoint 5
• 1 : 1 : 0: fixed speed setpoint 6
• 1 : 1 : 1: fixed speed setpoint 7
X X ✓ X X
16
SPD2
Level
17 SPD3 Level
18 TSET Level Torque setpoint selection.
This signal can select two torque setpoint
sources (one external torque setpoint, one
fixed torque setpoint).
• 0: external torque setpoint (analog input 2)
• 1: fixed torque setpoint
X X X ✓ X
19
SLIM1
Level
Speed limit selection.
A combination of SLIM1 to SLIM2 can select
four speed limit sources (one external speed
limit, three internal speed limits).
SLIM2 : SLIM1
• 0 : 0: internal speed limit 1
• 0 : 1: external speed limit (analog input 1)
• 1 : 0: internal speed limit 2
• 1 : 1: internal speed limit 3
✓ ✓ ✓ ✓ ✓
20 SLIM2 Level
21
POS1
Level
Select position setpoint.
A combination of the signals POS1 to POS3
can select eight fixed position setpoint sources.
POS3 : POS2 : POS1
• 0 : 0 : 0: fixed position setpoint 1
• 0 : 0 : 1: fixed position setpoint 2
• 0 : 1 : 0: fixed position setpoint 3
• 0 : 1 : 1: fixed position setpoint 4
• 1 : 0 : 0: fixed position setpoint 5
• 1 : 0 : 1: fixed position setpoint 6
• 1 : 1 : 0: fixed position setpoint 7
• 1 : 1 : 1: fixed position setpoint 8
X ✓ X X X
22
POS2
Level
23 POS3 Level
