Siemens SIMOTICS S-1FL6 User Manual

Connecting
4.3 Control/status interface - X8
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
129
No.
Name
Descriptions
Control mode
PTI
IPos
S
T
Fast
PTI
8 MBR Motor holding brake
• 1: the motor holding brake is engaged.
• 0: the motor holding brake is released.
Note
: MBR is only a status signal because the con-
trol and the power supply of the motor holding brake
are realized with separate terminals.
✓ ✓ ✓ ✓ ✓
9 OLL Overload level reached
• 1: the motor has reached the parameterizable
output overload level (p29080 in % of the rated
torque; default: 100%; max: 300%).
• 0: the motor has not reached the overload level.
✓ ✓ ✓ ✓ ✓
10 WARNING
1
Warning 1 condition satisfied
• 1: the parameterizable warning 1 condition has
been satisfied.
• 0: the parameterizable warning 1 condition has
not been satisfied.
See the note below on warning condition settings.
✓ ✓ ✓ ✓ ✓
11 WARNING
2
Warning 2 condition satisfied
• 1: the parameterizable warning 2 condition has
been satisfied.
• 0: the parameterizable warning 2 condition has
not been satisfied.
See the note below on warning condition settings.
✓ ✓ ✓ ✓ ✓
12 REFOK Referenced
• 1: referenced.
• 0: not referenced.
X ✓ X X X
13 CM_STA Current control mode
• 1: the second mode in five compound control
modes (PTI/S, IPos/S, PTI/T, IPos/T, S/T).
• 0: the first mode in five compound control modes
or four basic modes (PTI, IPos, S, T).
✓ ✓ ✓ ✓ X
