Siemens SIMOTICS S-1FL6 User Manual

Connecting
4.3 Control/status interface - X8
SINAMICS V90, SIMOTICS S-1FL6
130 Operating Instructions, 04/2019, A5E36037884-007
No.
Name
Descriptions
Control mode
PTI
IPos
S
T
Fast
PTI
14 RDY_ON Ready for servo on
• 1: the drive is ready for servo on.
• 0: the drive is not ready for servo on (a fault
occurs or the main power supply is missing).
Note:
after the drive is in "S ON" state, the signal
remains at high level (1) unless the above abnormal
cases happen.
✓ ✓ ✓ ✓ ✓
15 STO_EP STO active
• 1: the enable signal is missing, indicating that
STO is active.
• 0: the enable signal is available, indicating that
STO is inactive.
Note:
STO_EP is only a status signal for STO input
terminals but not a safe DO for the Safety Integrat-
ed function.
✓ ✓ ✓ ✓ ✓
Note: "X" means that the DO signal is not effective for this control mode and the value cannot be modified.
Assigning warning signals to digital outputs
You can assign two groups of warning signals to digital outputs with parameters p29340 (first
group of warning signals active) and p29341 (second group of warning signals active).
Setting (p29340/p29341)
Warning conditions
1 Overload protection: load factor is 85% of or above the motor utiliza-
tion.
2 Holding brake power overload warning: threshold p29005 has been
reached.
3
Fan alarm: fan has stopped for 1 second or longer.
4
Encoder alarm.
5 Motor overheat: motor has reached 85% of the maximum allowed
motor temperature.
6 Lifetime detection: the life expectancy of the capacity or the fan is
shorter than the specified time.
Note
If the warning condition(s) assigned to p29340 occur, WARNING1 becomes ON.
If the warning condition(s) assigned to p29341 occur, WARNING2 bec
omes ON.
