Control functions
7.8 Communicating with the PLC
SINAMICS V90, SIMOTICS S-1FL6
280 Operating Instructions, 04/2019, A5E36037884-007
Definition of register 40110
PTI, Fast PTI, IPos, S and T control modes
2 INP In-position signal
4 SPDR Speed reached
Warning 1 condition reached
Warning 2 condition reached
In the second control mode
The digital input signals can be simulated by Modbus with registers 40281 and 40283.
Register
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8 Bit 9
Register
40283 (p0796)
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8 Bit 9
● Set the simulation mode for DIs with register 40281
Bit 0 to bit 9 of register 40281 can be used to set the simulation mode for DI1 to DI 10.
For example, if you want to simulate DI1 with Modbus, you need to set bit 0 = 1 for
register 40281.
● Set the setpoint for DIs with register 40283
Bit 0 to bit 9 of register 40283 can be used to set the setpoint for the simulated DI signals.
After the DI simulation mode is set, you can set the setpoint for a DI signal with register
40283 to enable the DI signal. For example, if you have set bit 0 = 1 for register 40281, to
enable signal DI1, you need to set the trigger condition (rising edge or high level) for bit 0
of register 40283.
