Parameters
10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
369
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p29301[0..
.9]
Digital input 1 assignment
0
28
1
-
I16
IM
T
Description:
Defines the function of digital input signal DI1
• 1: SON
• 2: RESET
• 3: CWL
• 4: CCWL
• 5: G-CHANGE
• 6: P-TRG
• 7: CLR
• 8: EGEAR1
• 9: EGEAR2
• 10: TLIM1
• 11: TLIM2
• 12: CWE
• 13: CCWE
• 14: ZSCLAMP
• 15: SPD1
• 16: SPD2
• 17: SPD3
• 18: TSET
• 19: SLIM1
• 20: SLIM2
• 21: POS1
• 22: POS2
• 23: POS3
• 24: REF
• 25: SREF
• 26: STEPF
• 27: STEPB
• 28: STEPH
Index:
• [0]: DI1 for the control mode 0
• [1]: DI1 for the control mode 1
• [2]: DI1 for the control mode 2
• [3]: DI1 for the control mode 3
• [4...8]: Reserved
• [9]: DI1 for the control mode 9
