Parameters
10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
368 Operating Instructions, 04/2019, A5E36037884-007
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p29243 Positioning tracking acti-
vate
0 1 0 - I16 IM T
Description:
Activation of position tracking.
• 0: Deactivated
• 1: Activated
p29244 Absolute encoder virtual
rotary revolutions
0 4096 0 - U32 IM T
Description:
Sets the number of rotations that can be resolved for an encoder with activated position tracking
function (p29243 = 1).
p29245
Axis mode state
0
1
0
-
U32
IM
T
Description:
Linear/modulo mode:
• 0: Linear axis
• 1: Modulo axis
p29246 * Modulo correction range 1 214748264
7
360000 LU U32 IM T
Description: Sets the modulo range for axes with modulo correction.
p29247 * Mechanical gear: LU per
revolution
1 214748364
7
10000 - U32 IM T
Description: LU per load revolution.
p29248 * Mechanical gear: Numer-
ator
1 1048576 1 - U32 IM T
Description: (Load/Motor) Load revolutions.
p29249 * Mechanical gear: denom-
inator
1 1048576 1 - U32 IM T
Description: (Load/Motor) Motor revolutions.
p29250 PTI absolute position
mode enable
0 1 0 - U32 RE T
Description:
Absolute position mode enable.
• 1: Enable Absolute Mode
• 0: Disable Absolute Mode
p29300 Digital input forced sig-
nals
0 127 0 - U32 IM T, U
Description:
assignment signals are forced to be high. 7 bits in total.
• Bit 0: SON
• Bit 1: CWL
• Bit 2: CCWL
• Bit 3: TLIM1
• Bit 4: SPD1
• Bit 5: TSET
• Bit 6: EMGS
If one or more bits are set to be high, the corresponding input signals are forced to be logical high signals.
Note:
The drive unit displays the value in hex format. To know the logic (high/low) assignment to each bit, you
must convert the hex number to the binary number, for example, FF (hex) = 11111111 (bin).
